Aeromotive Adjustable Regulator - 3-15PSI - .313 Valve - (2) -08 Inlets/ -08 Return

P/N 13304 X1 Carbureted Return Style Regulator

Carbureted return style Regulator for Return Style Systems

Base fuel pressure adjustable from 3-20 PSI.

Vacuum/Boost reference capability.

1:1 rising rate for blow-through carburetors.

Gasoline, ethanol, alcohol and diesel compatible.

2 - ORB -08 inlet/outlet ports on the sides.

1 - ORB-08 return port on the bottom port.

1 - 1/8" NPT Gauge Port with plug.

1/16" NPT Boost Port with 5/32" hose barb.

Compatible with both X1 EFI Conversion kits.

0.313" return style with matching spring and poppet.

Handles up to 150 GPH with AN-08 return line.

Suitable for any Aeromotive pump up to A1000.

Mounting bracket included (not shown).

This product is not legal for sale or use on emission-controlled vehicles except when used as a direct replacement part matching OEM specifications.

X1 Regulator Service/Conversion Kits:

Include Seat, diaphragm/poppet assembly and spring

P/N 13014 150 GPH 0.313" Carb Service Kit

P/N 13013 150 GPH 0.188" EFI Conversion Kit

P/N 13015 250 GPH 0.313" EFI Conversion Kit

Pressure Range 3-20 PSI

Adjustable Yes

Minimum Pressure 3 PSI

Maximum Pressure 20 PSI

Mounting Bracket Included Yes

Port Quantity 2

Inlet Port Diameter ORB-08

Inlet Gender Female

Gauge Included No

Color Black

Grade Type Performance
